Paneltronics Breaker 15 Amps A-Frame Magnetic Waterproof

Panel Seal / Waterproof "A" Frame Magnetic Circuit Breakers

• Branch AC or DC circuit breaker for Paneltronics electrical distribution panels




• Meets all American Boat and Yacht Council (ABYC) Standards for non ignition protected circuit breakers




• UL Recognized (UL 1077) for use in the U.S.A., and CSA Certified for use in Canada




• Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)




• Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)

• Handle Color: Metal with Silicon rubber seal




• Maximum Amperage: 50 Amps




• Maximum Voltage/AIC: 32 VDC/ 2,500 Amps with no Back-up Fuse (ABYC E-11.10.1.5.5)




• Rated Switch Cycles: Rated Switch Cycles 10,000 actuations at rated current and voltage




• Electrical Hardware Screw: 10-32 x 3/8" pan combo head (P/N 197-188)




• Mounting Hardware: Hex nut 1/2-32 (supplied with circuit breaker)




• Lockwasher: 1/2" internal tooth (supplied with circuit breaker)




• Optional Boot: Black silicone rubber (P/N 048-015)
