Paneltronics 206-058S 50 Amps A-Frame Magnetic Waterproof Circuit Breaker

Out of stock
SKU: 29835 602290201473
Manufacture Part Number: 206-058S
Free Ground Shpping
Truck Freight: No
$32.95

Panel Seal / Waterproof "A" Frame Magnetic Circuit Breakers



  • Branch AC or DC circuit breaker for Paneltronics electrical distribution panels


  • Meets all American Boat and Yacht Council (ABYC) Standards for non ignition protected circuit breakers


  • UL Recognized (UL 1077) for use in the U.S.A., and CSA Certified for use in Canada


  • Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)


  • Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)


Specifications


  • Handle Color: Metal with Silicon rubber seal


  • Maximum Amperage: 50 Amps


  • Maximum Voltage /AIC: 32 VDC/ 2,500 Amps with no Back-up Fuse (ABYC E-11.10.1.5.5)


  • Rated Switch Cycles: Rated Switch Cycles 10,000 actuations at rated current and voltage


  • Electrical Hardware: Screw 10-32 x 3/8" pan combo head (P/N 197-188)


  • Mounting Hardware: Hex nut 1/2-32 (supplied with circuit breaker), Lockwasher 1/2" internal tooth (supplied with circuit breaker)


  • Optional Boot: Black silicone rubber (P/N 048-015)


The Paneltronics 206-058S 50 Amps A-Frame Magnetic Waterproof Circuit Breaker is designed for reliable performance in marine environments. This branch AC or DC circuit breaker meets all American Boat and Yacht Council (ABYC) standards for non-ignition protected circuit breakers and is UL Recognized for use in the U.S.A., as well as CSA Certified for Canada. With a trip-free feature, this circuit breaker ensures safety and efficiency, making it an essential component for your electrical distribution panels.

Features:
* Branch AC or DC circuit breaker designed for Paneltronics electrical distribution panels
* Meets ABYC standards for non-ignition protected circuit breakers
* UL Recognized (UL 1077) and CSA Certified for use in North America
* Trip-free design ensures safety during electrical faults
* Manual reset functionality for ease of use
* Handle color features a durable metal construction with silicon rubber seal
* Maximum amperage rated at 50 Amps for reliable performance
* Can operate at 32 VDC/2,500 Amps without a backup fuse
* Rated for 10,000 switch cycles at rated current and voltage
* Includes necessary mounting hardware for easy installation
