Paneltronics 206-054S 20 Amp A-Frame Magnetic Waterproof Circuit Breaker

Out of stock
SKU: 29831 602290201435
Manufacture Part Number: 206-054S
Free Ground Shpping
Truck Freight: No
$32.95

Panel Seal/Waterproof "A" Frame Magnetic Circuit Breakers



  • Branch AC or DC circuit breaker for Paneltronics electrical distribution panels


  • Meets all American Boat and Yacht Council (ABYC) Standards for non ignition protected circuit breakers


  • UL Recognized (UL 1077) for use in the USA and CSA Certified for use in Canada


  • Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)


  • Manual reset (ABYC E-11.10.1.5.6. and E-11.10.2.1.1)


Speficiations:


  • Handle Color: Metal with Silicon rubber seal


  • Maximum Amperage: 50 Amps


  • Maximum Voltage/AIC: 32 VDC/2500 Amps with no Back-up fuse (ABYC E-11.10.1.5.5)


  • Rated Switch Cycles: Rated Switch Cycles 10,000 actuations at rated current and voltage


  • Electrical Hardware: Screw 10-32 x 3/8" pan combo head (P/N 197-188)


  • Mounting Hardware: Hex nut 1/2-32 (supplied with circuit breaker), Lockwasher 1/2" internal tooth (supplied with circuit breaker)


  • Optional Boot: Black silicone rubber (P/N 048-015)


The Paneltronics 206-054S 20 Amp A-Frame Magnetic Waterproof Circuit Breaker is designed for reliable performance in marine electrical systems. This branch circuit breaker is suitable for both AC and DC applications, ensuring compliance with all American Boat and Yacht Council (ABYC) standards for non-ignition protected devices. With UL recognition and CSA certification, this circuit breaker guarantees safety and effectiveness in both the USA and Canada. The trip-free and manual reset features enhance usability, making it a must-have for your electrical distribution panels.

Features:
* Branch AC or DC circuit breaker designed for Paneltronics electrical distribution panels
* Meets all American Boat and Yacht Council (ABYC) standards for non-ignition protected circuit breakers
* UL Recognized (UL 1077) for use in the USA and CSA Certified for use in Canada
* Trip free operation for enhanced safety
* Manual reset feature for convenient operation
* Metal handle with a silicone rubber seal for durability
* Maximum amperage of 50 Amps for robust performance
* Maximum voltage/AIC rating of 32 VDC/2500 Amps with no back-up fuse
* Rated for 10,000 switch cycles at rated current and voltage
* Includes necessary mounting hardware and optional black silicone rubber boot available
