Lumishore ECLIPSE SMX24 Surface Mount Blue LED
Model: 60-0531 / 010-04501-00Specifically designed for smaller boats, the SMX24 - Blue offers unmatched light output and optics for a light of its compact size. Flooding the water with 3,100 fixture lumens of light in a 90° beam.
It's built-in driver and simple 2-wire connections make the installation of this light easier than ever.
Suitable for stepped hulls, transoms, and hull side installations.
Controlled by an ON/OFF switch or the ECLIPSE Command Center.
SpecificationsCOLOR
BLUE
LUMENS
6,975
VERIFIED FIXTURE LUMENS (WHITE)
3,100
NUMBER AND TYPE OF LEDS
BLUE 12X3W
LED POWER - HICOB ARRAY
YES
TYPICAL LED LIFE
50,000+ HOURS
BEAM ANGLE (DEGREES)
90°
DRIVER
MULTI-CHANNEL INTERNAL DRIVER
SUPPLY VOLTAGE (12 V DC ONLY)
10.5—14.5 V DC
MAX CURRENT DRAW
2.5A
HOUSING TYPE
MARINE BRONZE BODY/ GLASS LENS
USER CONTROL OPTIONS
STANDARD ON/OFF SWITCH OR ECLIPSE COMMAND CENTER
DIMMING CONTROL
YES
