Iris Innovations IRIS-S476 Marine Grade Stainless Steel Recess Mount Dome Camera - 3MP HD IP Vertical Surface Mount

HD IP Flush Vertical Surface Mount - 3MP Max Resolution - 316L Marine Grade Stainless Steel - Recess Mount Dome

Iris Sx76 series camera is the first of its kind designed to be installed into a bulkhead or vertical surface. Its waterproof stainless steel case is machined from marine-grade 316L stainless steel, which means it will not corrode in harsh saltwater environments, making it a great option as a backup or docking camera for boats. By mounting the camera on the sides of your boat, it can even be used when mooring alongside jetties or pontoons.

During installation, the cameras inner ball can be adjusted and then locked into position by simply tightening the outer bezel to achieve the desired view.

For IP-based systems, the S476 features 3MP high-definition resolution and 12VDC or PoE power.

As well as marine applications, the camera's tough case, and small footprint make it a perfect visibility aid for recreational vehicles, fire and rescue trucks, and other applications where a robust and reliable high-definition camera is required.

The camera is certified to EN60945, EN55032, EN55035, and EN60529 (IP66) and is ONVIF compliant. For marine applications, the camera is directly compatible with Raymarine LH2 and above, Simrad, Lowrance, and B G. For Garmin systems, use them in conjunction with Iris CMAC systems.

Features:

• 1.8mm Standard (160-degree horizontal field of view)


• Corrosion-Proof 316L Marine Grade Stainless Steel


• 3MP Hi-Def IP Camera Format


• IP Version - max. 3MP Hi-Def resolution


• Super wide angle 160-degree lens


• IP version supports PoE and 12VDC - ultra-low power


• Built-in infrared LED illumination (10m range)


• EN60945, EN55032, EN55035, EN50529 (IP66) , FCC, CE


• Shock vibration proof


• Super rugged and easy to install

Applications:

• Perfect for extreme environments


• Workboats tug boats


• Fishing vessels


• Engine room monitoring


• Law enforcement military


• Wind farm vessels


• SUVs, RVs, work vehicles, and trucks


• Luxury vessels


• Passenger ferries cruise liners

Specifications:

• Lens (millimeter): 1.8mm


• Horizontal Field of View: 160-degree HFOV


• Sensor (inch): Sensor 1/4 CMOS Sensor


• Resolution: Variable - 3MP Max (2304 x 1296)


• Interface: RJ45 10/100 Base T Ethernet


• Video Processing: H.264 Codec / Dual Stream


• Protocols/Video Format: TCP/UDP/HTTP/Multicast/UPnP/NTP/RTSP/ONVIF


• Onvif: Profile S v21.06


• Bitrate: VBR / CBR 32kbps 8Mbps


• Illumination: 6 x 850nm Infra-Red - 10-meter range


• Lens/Field of View: 1.8mm Standard (160-degree HFOV)


• Mirroring: Horizontal Vertical - Configure via Browser


• Automatic Gain Control: Supported / multiple levels


• Compatibility: Raymarine / Axiom (LH2 or higher), Simrad / B G / Lowrance (Latest NOS / NEON OS) / PC-based systems, MFDs with digital (HDMI / DVI) Input, MFDs via IRIS NVR/HVR, IE Browser


• Operating Temperature: -30 + 60-degrees C


• Connections: Video: Water Resistant RJ45 Socket / Non-PoE with DC Power Socket


• Material: Marine Grade 316L Stainless Steel (highly polished as a standard)


• Power: +12VDC (+10 +15VDC Range) / 1W Nominal / 1.8W Max (LEDs ON)


• Power Over Ethernet (PoE): IEEE802.3af


• Weight Dimensions: 88mm x 22.25mm above and below the mounting surface


• Environmental: EN60529 / IP66


• EMC: EN55032:2015/A11:2020 EN55035:2017/A11:2020 EN60945:2002 Sections 9 10 / PoE with Compliant PoE Injector / FCC Part 15 A B


• RoHS: EN6300:2018

The Iris Innovations IRIS-S476 is a rugged and reliable high-definition IP camera designed for vertical surface and bulkhead mounting in harsh environments. Crafted from corrosion-proof 316L marine-grade stainless steel, this camera offers exceptional durability against saltwater exposure, making it ideal for marine applications such as workboats, fishing vessels, and luxury yachts. Its compact design allows easy installation on the sides of boats, enabling clear visibility even when mooring alongside jetties or pontoons. The camera's adjustable inner ball and locking outer bezel facilitate precise positioning, ensuring optimal viewing angles to suit specific monitoring needs.

Equipped with a 3MP CMOS sensor and a super wide 160-degree field of view, the IRIS-S476 captures high-definition footage with sharp clarity. The camera supports Power over Ethernet (PoE) and 12VDC power sources, providing versatile installation options with minimal cabling. Built-in infrared LEDs extend visibility up to 10 meters in low-light conditions, enhancing security and situational awareness during nighttime or low-light environments. Certified to IP66 standards and compliant with EN60945, EN55032, EN55035, and EN60529, this camera withstands shock, vibration, and extreme temperatures from -30?C to +60?C, ensuring consistent performance in demanding conditions.

Designed for seamless integration, the IRIS-S476 is compatible with Raymarine LH2 and higher, Simrad, Lowrance, and B&G marine systems, as well as PC-based systems and MFDs via IRIS NVR/HVR or browser interfaces. Its advanced video processing utilizes H.264 codec with dual streaming capabilities, supporting multiple protocols including TCP, UDP, HTTP, and ONVIF Profile S v21.06. Whether used for marine surveillance, engine room monitoring, or security on work trucks and rescue vehicles, this camera offers a perfect combination of durability, high resolution, and ease of installation for a wide range of demanding applications.

Features:
* 1.8mm standard lens with 160-degree horizontal field of view
* Corrosion-proof 316L marine-grade stainless steel housing
* 3MP high-definition IP camera with sharp image clarity
* Support for PoE and 12VDC power sources for flexible installation
* Built-in infrared LEDs with 10-meter illumination range
* Certified IP66 waterproof and dustproof enclosure
* Shock and vibration resistant construction
* Easy to adjust inner ball for precise positioning
* Compatible with leading marine and digital systems including Raymarine, Simrad, Lowrance, and B&G
* Supports multiple protocols and ONVIF Profile S v21.06 for easy integration
