Garmin ECHOMAP Ultra 2 166sv ICE House System - 010-03386-02

Garmin ECHOMAP Ultra 2 166sv ICE House System WITH ICE House System

• 16-INCH FULL HD IPS TOUCHSCREEN DISPLAY


• SHARE TO YOUR TV OR EXTERNAL DISPLAY VIA HDMI OUTPUT


• LIVESCOPE FORWARD AND LIVESCOPE DOWN MODES


• PRELOADED WITH GARMIN NAVIONICS+ MAPPING OF 25,000+ INLAND AND COASTAL LAKES

Upgrade your on-ice experience with the ECHOMAP Ultra 2 16-inch chartplotter, LiveScope Plus System and everything else you’d want to help you catch more fish.

ECHOMAP ULTRA 2 16-INCH: This chartplotter features a 16-inch full HD IPS display with touchscreen, mapping and HDMI output, so you can display sonar on your TV or external display.

ICE HOUSE SYSTEM: Get a GLS 10 sonar black box with swivel pole mount and an LVS34-IF transducer, which features a transducer cable that stays flexible — even in freezing conditions.

LIVESCOPE MODES: With an included 0-degree pole mount, the transducer can quickly switch between LiveScope Forward and LiveScope Down modes to adapt to your fishing technique.

GARMIN NAVIONICS+ MAPPING: Get coverage for more than 25,000 lakes with preloaded coastal and inland mapping.

CUSTOM COMBOS: Create custom pages that combine sonar and maps on your display.

BUILT-IN SONAR: See below and around your boat with built-in sonar capabilities, whether you’re on the ice or the open water.

Dimension
16.9" x 10.5" x 3.14" (43.0 x 26.6 x 8.0 cm)

Weight
9.5 lbs (4.31 kg)

Water rating
IPX7

Touchscreen
Yes

Display Type
FHD, IPS

Display Size
13.6" x 7.7"; 15.6" diagonal (34.5 cm x 19.5 cm; 39.7 cm diagonal)

Display resolution
1920 x 1080 pixels

Input
Touchscreen with Keyed Assist

Maps & Memory

Accepts Data Cards
2 microSD cards

Waypoints
5000

Track points
50,000

Tracks
50 saved tracks

Navigation Routes
100

Ice Fishing Details

Included transducer
LiveScope Plus System with LVS34-IF

Transducer holding feature
Pole mount

Sonar Features

Power output
600 W

Traditional sonar (dual frequency/beam)
Built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)

ClearVu
Built-in 260/455/800/1000/1200 kHz

SideVu
Built-in 260/455/800/1000/1200 kHz

Panoptix sonar
Yes

LiveScope
Yes

Connections

NMEA 2000® ports
1

Video output ports
1 HDMI

Garmin Marine Network Ports
2

12-pin transducer ports
12-pin scanning sonar

Bluetooth pairing
Yes

ANT (Connectivity)
Yes

Garmin Wi-Fi network (local connection)
Yes

Input Voltage
9 to 18 Vdc

What's in the Box:

• ECHOMAP Ultra 2 166sv with preloaded Garmin Navionics+ Inland, Coastal and Offshore Mapping for U.S. or Canada


• LiveScope Plus LVS34-IF transducer


• GLS 10 black box sonar module with power and network cables


• Ice fishing pole mount


• 0° shaft mount


• Power and network cables


• Hardware


• Documentation
