ASEA Power Systems 12 kVA Marine Isolation Transformer with Ground Fault Protection - 634103

12 kVA Isolation Transformer

ASEAs Isolation Transformer is a drop-in replacement for Charles IsoG2, designed to protect vessel under-fittings from galvanic corrosion and to shield onboard electronics from reverse polarity and shore power fluctuations. It also ensures safety by preventing the boat from sending unintended electric currents into the surrounding water.

Features:

• Ignition-protected, safe for gasoline-powered vessels
• Complete Electrical Isolation prevents dockside ELCI breaker trips
• Maintains a safer marine environment by mitigating the risk of ESD
• Ensures clean and stable AC power for on-board equipment
• Reduces galvanic corrosion
• Meets the latest NEC 555.35 marina code that ensures GFPE limits are not exceeded

Specifications:

• Input Voltage: 120 VAC
• Input Current: 30 A
• Output Voltage: 120 VAC
• Output Current: 30 A
• Output Frequency: 60 Hz
• Weight: 55 lbs
• Height: 21.6 cm / 8.5 in
• Width: 21.6 cm / 8.5 in
• Width (with flange): 27.4 cm / 10.8 in
• Depth: 26.7 cm / 10.5 in

Certifications:

• ABYC E-11 Compliant
• ABYC C-1500 (for ignition protection)
• UL 1500 (for ignition protection)
• UL 1561

The ASEA Power Systems 12 kVA Isolation Transformer is designed specifically for marine applications, offering reliable electrical isolation to protect vessel electronics and reduce galvanic corrosion. This transformer acts as a drop-in replacement for the Charles IsoG2, ensuring compatibility and ease of installation on a variety of boats and yachts. Its ignition-protected design makes it safe for gasoline-powered vessels, while its ability to prevent dockside ELCI breaker trips enhances onboard safety and compliance with marine electrical standards. The unit maintains a clean, stable power supply for all on-board equipment, minimizing the risk of electrical disturbances and protecting sensitive electronics from power fluctuations and reverse polarity issues. By ensuring complete electrical isolation, the transformer helps mitigate electrostatic discharge (ESD) and reduces corrosion caused by galvanic currents, extending the lifespan of underwater fittings and electrical components. It also complies with the latest National Electrical Code (NEC 555.35) marina requirements, ensuring that GFCI protection limits are not exceeded for added safety and regulatory adherence. The transformer features a compact design with a weight of approximately 55 pounds, and its dimensions are optimized for easy integration into existing electrical systems. Its robust certification, including ABYC E-11, ABYC C-1500, UL 1500, and UL 1561, confirms its suitability for marine environments and safety standards. The unit provides 120 volts AC at 30 amps both input and output, with a 60 Hz frequency, delivering consistent power that enhances onboard operational reliability and safety. For detailed installation instructions and safety information, refer to the owner's manual available online. This product is a practical solution for boat owners seeking to improve electrical safety, reduce corrosion, and ensure compliance with maritime electrical codes, all in a durable, compact package.

Features:

• Ignition-protected design for gasoline-powered vessels

• Complete electrical isolation prevents dockside ELCI breaker trips

• Mitigates electrostatic discharge (ESD) for a safer marine environment

• Provides clean and stable 120 VAC power for onboard equipment

• Reduces galvanic corrosion to extend underwater fitting lifespan

• Meets latest NEC 555.35 marina code for GFCI limits

• Certified by ABYC, UL for ignition protection and marine safety standards
