Lumishore ORA THX204 Thru-Hull Mount Blue LED - 010-04514-00
Free Ground Shipping ( 2-6 Day Delivery Time )
Truck Freight: No
⏳ Hurry! Only 1 left in stock
Contact: 866-675-8464
30-day returns available
Manufactures Part Number: 010-04514-00
Truck Freight: No
Lumishore ORA THX204 Thru-Hull Mount Blue LED
Model: THX204 / 010-04514-00Lumishore's ultra-slim thru-hull THX204 has a small hull cut out requirement of only 5/8" (16.5mm). Blue LED
The THX204 features 6,100 fixture lumens and an ultra-wide 110°beam angle, allowing the light to saturate deep into the water.
With a simple 2-wire installation and no external drivers, it's one of the easiest thru-hull lights to install and is suitable for transom, side hull or bottom installations.
Control the THX204 by a standard on/off switch.
SpecificationsCOLOR
BLUE
LUMENS
13,725
VERIFIED FIXTURE LUMENS (WHITE)
6,100
NUMBER AND TYPE OF LED
Blue — 24 x 3W High Power LED
LED POWER - HICOB ARRAY
YES
TYPICAL LED LIFE
50,000+ HOURS
BEAM ANGLE (DEGREES)
110°
DRIVER
MULTI-CHANNEL INTERNAL DRIVER
SUPPLY VOLTAGE
12/24 V DC
MAX CURRENT DRAW
4.9A/2.4A
HOUSING TYPE
MARINE GRADE ALUMINUM BRONZE
USER CONTROL OPTIONS
ON/OFF SWITCH
Warranty
3 Years
What's in the Box:
- One (1) ORA THX204 Light with Built-in Driver
